We offer electro-hydraulic controls for mobile equipment, including valve electronics, single solenoid controllers, dual solenoid drivers for proportional and directional valves, potentiometer and PWM controlled solenoid drivers, battery chargers, motor controllers, switch mode power supplies, networked control systems, remote mount solenoid driver, valve drivers for proportional cartridge valves, controllers with feedback, soft shift driver, joystick interfaces, electronic controllers, PID controllers, electronic controls with position feedback, motor controls, I/O controls, pulse width modulation (PWM) drivers or converters, coil saver, distributed controls, networked control systems including CAN bus (SAE J1939, CANopen) and other fieldbus controls, enable keypad for material handling equipment, actuator controls and other electronic machine controls, components and systems for material handling, off-road construction equipment, off-highway vehicles, lift equipment, agricultural equipment, power generation, and industrial OEM markets.

Axiomatic also offers flexible configuration with our Electronic Assistant®.

Mobile Electronics
Battery Chargers Multi-functional and efficient charging Distributed I/O functionality CAN system integration Rugged performance Inherent power factor correction Machine mount Power LED indicator IP67 - Fully sealed remote mount enclosure Click on a part number for Technical Data. Part Numbers: AX090003 - 24V, 10A AX090004 - 12V, 10A Use Electronic Assistant® for easy, flexible configuration.	Click image for Product Overview.
Motor Controls with CAN Flexible, accurate motor control Discrete I/O functionality Permits CAN system integration Rugged performance Click on a part number for Technical Data. Part Numbers: AX100050 - DC, 12/24VDC, 150 A AX100100 - DC, 12/24VDC, 25 A AX100200 - BLDC, 12/24VDC, 20 A AX100300 - DC, 12/24VDC, 12 A Use Electronic Assistant® for easy, flexible configuration. Contact Axiomatic with application-specific motor control requirements.	Click image for Product Overview.
DC to DC Converters DC-DC converters can provide stable DC supply when installed on battery-powered vehicles or generator sets. Battery taps can be avoided and sensitive equipment is protected. Power regulation for sensitive electronics Isolation when required for critical loads Power conditioning of on-site batteries No cooling fan required IP67 for harsh environements Click on a part number for Technical Data. ISOLATED DC-DC CONVERTERS 12(24)VDC to 24VDC, 120 Watts, 5A 24VDC to 24VDC, 240 Watts, 10A 24VDC to 12VDC, 60 Watts, 5A 24VDC to 48 VDC, 144 Watts, 3A 24VDC to 26VDC,130 Watts, 5A 48VDC to 24 VDC, 240 Watts, 10A NON-ISOLATED DC-DC CONVERTERS 72VDC to 24VDC, 315 Watts 72VDC to 12VDC, 180 Watts 48VDC to 24VDC, 315 Watts 48VDC to 12VDC, 180 Watts 42VDC to 24VDC, 315 Watts 42VDC to 12VDC, 180 Watts 24VDC-120VDC, 240 Watts	Click image for Product Overview.
Engine Controls Axiomatic engine control components provide rugged, reliable solutions for a variety of engine control automation appliations. From engine temperature monitoring over CAN bus, interfacing with an engine control unit (ECU) to drive auxiliary functions such as hydraulic valves and expanding control system capability with on-board I/O, Axiomatic advanced electronics provide efficient and safe engine operation. Our controls are field-proven and use robust circuits and rugged packaging for use in harsh environments. Click on a part number for Technical Data. Part Numbers: AX030100 - 10 Analog Input to CAN Control (CANopen version available on request) AX030200 - 16 Analog Input Control AX030300 - 18 Digital Input, CAN Output AX030600 - 5 Digital Input to CAN Controller DIO128 - 12 discrete inputs to 8 relay outputs AXTC4 - Thermocouple Scanner Module, 4 Channel AXTC20 - Thermocouple Scanner Module, 20 Channel AXRDT8 - RTD Module Use Electronic Assistant® for easy, flexible configuration. In addition to off-the-shelf products, Axiomatic can provide an OEM solution to meet your design project requirements.	Click image for Product Overview.
Displays An Axiomatic operator interface module provides engine monitoring, transmission monitoring or implement control in a machine CAN network. An Axiomatic display combined with Axiomatic inclinometers, valve drivers or signal level I/O modules can represent an OEM application platform for a vehicle control system solution. All display modules are designed for harsh operating environments.	Click image for Product Overview.
Controllers for Proportional Fan Drive Systems Control of the rotational speed of a fan-drive motor is achieved by an Axiomatic Fan Controller driving a HydraForce TS Pressure Relieving Electro-Proportional Cartridge Valve. Variable control of the rotational speed of a fan-drive motor provides maximum efficiency and noise control for operation of the engine cooling fan system. Applications include motor vehicles (trucks and buses), agricultural equipment, construction equipment, and stationary power plants. Click on a part number for Technical Data. Part Numbers: CAPV-H-5V-2A - 0-5VDC input, 2A output, AX021800 - 4 Input, Dual Valve Controller AX020200 - Economy Fan Controller AX021500 - Fan Drive Controller, mulitple inputs, single output Use Electronic Assistant® for easy, flexible configuration. Contact Axiomatic with application-specific cooling system requirements.	Click image for Product Overview..
Signal Converters Our wide variety of industry standard data signal conversion modules provide complete, cost-effective solutions for interfacing, conditioning and distributing critical analog signals. Axiomatic signal converters typically accept an external universal power of 12V, 24V or 36V and provide input-to-output isolation. Signal isolation protects measurement and control signals as well as sensitive controls from the effects of noise, power surges and other hazards present in industrial data acquisition and battery-powered machine environments. The modules are designed to mount on a DIN rail. Click on a part number for Technical Data. Part Numbers: CURRENT CONVERTERS IC-DR-11 - 4-20 mA to 0-200 mA IC-DR-12 - 4-20 mA to 20-160 mA IC-DR-13 - 4-20 mA to +/- 10 to +/- 310 mA, Bipolar Output IC-DR-14 - 4-20 mA to 0-50 mA IC-DR-16 - +10 to -10VDC to +/- 10 to +/- 310 mA, Bipolar IC-DR-18 - 4-20 mA to +/- 40 to +/- 160 mA, Bipolar Output IC-DR-19 - +5 to -5VDC to +/- 10 to +/- 310 mA, Bipolar IC-DR-20 - 4-20 mA to 0-100 mA IIC-DR-22 - 0-200 mA to 4-20 mA, Three-way Isolation PWM CONVERTERS IPWM-DR-200MA - 0-200 mA to PWM IPWM-DR-4-20MA - 4-20 mA to PWM VPWM-DR-10V - 0-10V to PWM VPWM-DR-5V - 0-5V to PWM PWMV-DR-B1V - PWM to +/-1VDC, Bipolar Output PWMI-DR-200MA - PWM to 0-200 mA PWMI-DR-20MA - PWM to 0-20 mA PWMI-WG8-0y - 3 sec. response y = 1 (0-5VDC) 2 (0-10VDC) 3 (0-20mA) 4 (4-20mA) PWMI-WG8-0y - 100 msec. response y = 5 (0-5VDC) 6 (0-10VDC) 7 (0-20mA) 8 (4-20mA) AX130100 - PWM to 0-5V, 3 Channel UNIVERSAL SIGNAL CONVERTER USC-CVB225-01 - PWM/Current/Voltage to PWM/Current/Voltage, 3-way isolation, 12/24/48VDC, DIN rail, IP00 LVDT OR RVDT SIMULATOR LVDTS-DR-02 - The LVDT Simulator is used to test LVDT or RVDT sensors.	Click image for Product Overview.
Transmission Controllers Simple open and closed loop controls for efficient control of mobile or marine transmissions Click on a part number for Technical Data. Part Numbers: AX021800 - Fan Drive Controller AX021101 - 32 Input/Output Use Electronic Assistant® for easy, flexible configuration. Contact Axiomatic with application-specific transmission control requirements.	Click image for Product Overview.
Valve Drivers with CAN Standard hardware platforms in rugged packages for mobile equipment Standard software (application-specific setpoints on request) Drives multiple valves (proportional and on/off) Interfaces to multiple command inputs, switches, sensors and other inputs Wide ranging power supply input Networked solutions as part of total machine control Click on a part number for Technical Data. Part Numbers: AX020100 - Single Proportional or On/Off Output AX021200 - 72V, 9 Output CAN Controller, SAE J1939 (CANopen version available on request) AX021300 - 6 Digital Output (CANopen version available on request) AX021600 - Single Channel CAN Controller (CANopen version available on request) AX021800 - 2 Universal Inputs, 2-2A Outputs AX021900 - 6 Universal Analog Inputs, 4 Outputs AX022000 - 1 Universal Input, 2 Outputs Use Electronic Assistant® for easy, flexible configuration.	Click image for Product Overview.
Double Solenoid Driver - DIN 43650 The digital controller supplies one or two proportional solenoid coils with current proportional to an input control. All calibration settings are managed by a microprocessor for accurate control of hydraulic and pneumatic proportional solenoid valves used in mobile construction equipment and industrial processes. An external handheld programming device calibrates the controller. Click on a part number for Technical Data. Part Numbers: DCAPV-H-1-2A - Single Output (0-5 V/ Potentiometer/ 0-10 V/+/-5V/ +/-10V/ 4-20 mA command inputs, output 0-2 A) DCAPV-H-2-2A - Dual Output (0-5 V/ Potentiometer/ 0-10 V/+/-5V/ +/-10V/ 4-20 mA command inputs, output 0-2 A) DCAPV-PRG - Handheld Programming Device	Click image for Product Overview.
ANALOG VALVE DRIVERS - Proportional Valve Controller/Amplifier - Coil Mount This proportional valve controller/amplifier offers performance in a small package. Efficient power circuitry, independent ramp adjustments, and ease of use are the main design features. It supplies a solenoid valve with current proportional to an input control (0-5 VDC, 0-20 mA, potentiometer or pre-set level). A wide range of power supply voltages from 9 to 32 VDC are accepted. This linear solenoid controller utilizes high frequency switching output (PWM) to provide a maximum DC current output of 2000 mA, 1600 mA, 1200 mA, 800 mA or 600 mA. The user can adjust maximum and minimum current. A current sensing circuit maintains current output regardless of changes in input voltage or coil resistance. The superimposed dither frequency and amplitude can also be adjusted to suit the application. The unit utilizes a DIN 43650 connector for mounting directly on the coil. The controller is CE certified. UL listed versions are available. Click on a part number for Technical Data. Part Numbers: CAPV-H-5V-2A - 0-5VDC input, 2A output, , IP67 CAPV-H-5V-1.2A - 0-5VDC input, 1.2A output, , IP67 CAPV-H-5V-600MA - 0-5VDC input, 600 mA output,, IP67 Other control signal input versions are available including 4-20 mA and 0-10 VDC.	Click image for Product Overview.
ANALOG VALVE DRIVERS - Economy Version: Proportional Valve Controller/Amplifier - Coil Mount The economy version of the proportional valve controller/amplifier simplifies control of proportional solenoids by supplying a current proportional to an input control (0-5 VDC or 10K potentiometer). This linear solenoid controller utilizes high frequency switching output (PWM) to provide a DC current output. Maximum current output is 2 Amps (1 Amp version available). A current sensing circuit maintains current output regardless of changes in input voltage or coil resistance. The user can adjust maximum and minimum current. Dither frequency and amplitude are factory set. In this economy version of the controller/amplifier there are no ramps. The unit is available with a DIN 43650 connection to mount directly on the coil and comes complete with 2 meters of unterminated cable. The controller has a CE mark for compliance to the EMC Directive. Click on a part number for Technical Data. Part Numbers: CAPVE-H-5V-2A-5C-2M - 0-5V input, 2A output CAPVE-H-5V-1A-5C-2M - 0-5V input, 2A output CAPVE-H-4-50MA-2A-4C-2M - 0-5V input, 2A output	Click image for Product Overview.
ANALOG VALVE DRIVERS - Proportional Valve Driver - Remote Mount The proportional valve driver can be mounted remote from the valve, providing an efficient way to drive the solenoid as well as convenient packaging and diagnostics. The unit accepts 0-5 VDC, 0-20 mA and 10K potentiometer inputs. LED's indicate power levels and status. Ramp or dither adjustments are straightforward with easily accessible potentiometers. Maximum DC current outputs available include: 2000 mA, 1600 mA, 1200 mA, 800 mA or 600 mA. The unit is available as a stand alone PCB board or as a DIN rail mount unit (shown) for mounting in a control cabinet or packaged in an IP67 rated metal box complete with cable. The controllers have a CE mark for compliance to the EMC directive. Click on a part number for Technical Data. Part Numbers: PCB BOARD RSD-PCB-5V-x PACKAGED DRIVER (board installed in housing assembly) RSD-SMB-5V-x-00 - available with no cable RSD-SMB-5V-x-01 - available with 3 connectors RSD-SMB-5V-x-IP5-yM - IP65 rated and available with cable - 5 ft. (1.5m) or 10 ft. (3m) RSD-SMB-5V-x-IP7-yM - IP67 rated and available with solid round cable - 5 ft. (1.5m) or 10 ft. (3m) DIN RAIL RSD-DR-5V-x Where: x =maximum current output (2A, 1.2A, 600MA or 400MA) y=1.5, 3 or custom lengths (meters) Other control signal input versions are available including 4-20 mA and 0-10 VDC.	Click image for Product Overview.
ANALOG VALVE DRIVERS - Soft Shift Controller - Coil Mount The soft shift controller introduces a current ramp permitting the soft start of proportional solenoid valves used for pressure or flow control in hydraulic circuits. Various ramp times can be accomplished. Both 2A and 650 mA maximum current output versions are available. Ramp times include 0-5 seconds, 5-10 seconds or customer-specific times. Click on a part number for Technical Data. Part Numbers: SSD-H-2-02-2A-2M - 225 Hz, 5-10 seconds, 2A, 2 m 2 conductor cable, IP65 SSD-H-1-02-2A-2M - 225 Hz, 0-5 seconds, 2A, 2 m 2 conductor cable, IP65 SSD-H-1-02-650MA-2M - 650 mA, 225 Hz, 0-5 seconds, 2 m 2 conductor cable, IP65 SSD-H-2-02-650MA-2M - 650 mA, 225 Hz, 5-10 seconds, 2 m 2 conductor cable, IP65	Click image for Product Overview.
ANALOG VALVE DRIVERS - Dual Solenoid Multifunction Valve Driver The dual solenoid multifunction valve driver provides accurate control of hydraulic proportional and directional valves used in mobile equipment and industrial processes, with input from a joystick, potentiometer or control system interface. This multifunctional design will support inputs from a joystick potentiometer with or without center tap, a standard potentiometer or commonly available control signals such as 0 to 5 Volts, 0 to +/-5 Volts, 0 to 10 Volts, 0 to +/-10 Volts, 0 to 20 mA, and 0 to +/-20 mA. A 4-20 mA input model is also available (contact the manufacturer for details). The power supply connection is conditioned to withstand the harsh environment found in vehicular power systems. Maximum current output is adjustable from 0 to 2 Amps. A high low range input provides reduced output for operation in confined spaces. The driver is potted and available as a packaged driver enclosed in an IP67 rated metal housing with flat tab style connections. Click on a part number for Technical Data. Part Numbers: DSDA-SMB-TB-01 - 0 to 5V, 0 to +/-5V, 0 to 10V, 0 to +/-10V, 0 to 20mA, 0 to +/-20mA selectable input, 0-2A output, two proportional outputs, on/off outputs DSDA-SMB-SC-01 - 0 to 5V, 0 to +/-5V, 0 to 10V, 0 to +/-10V, 0 to 20mA, 0 to +/-20mA selectable input, 0-2A output, two proportional outputs, on/off outputs DSDA-SMB-TB-01-300MA - 0 to 5V, 0 to +/-5V, 0 to 10V, 0 to +/-10V, 0 to 20mA, 0 to +/-20mA selectable input, 0-300mA output, two proportional outputs, on/off outputs	Click image for Product Overview.
ANALOG VALVE DRIVERS - Proportional Speed Controller with Manual Potentiometer The speed controller is a low-cost cost manual velocity controller designed to interface between 12 or 24V battery power and a remote grounded proportional solenoid valve. The controller is suited for use in material handling equipment and proportional hydraulic circuits found in a variety of mobile and industrial applications. It is available in a remote metal box or as a panel mount version. Key features of the controller include: Accepts a wide range of input operating voltages (12 or 24 VDC nominal) Manual control with a built-in potentiometer Regulated output of 2 Amps (adjustable) Efficient control Minimum output current adjustment to compensate for valve deadband Fixed superimposed dither to reduce valve hysteresis Reverse polarity protection inherent in design Short circuit protection Filter eliminates electrical noise Robust, rugged and highly reliable Compact size Direct panel mount or mounted in a metal box for remote control of a proportional solenoid Interfaces to a grounded solenoid (not supplied) Operational from -40 to 85°C Click on a part number for Technical Data. Part Numbers: CC-01 - panel mount version (Integral potentiometer input, 2A output, no ramps, fixed dither) CC-SMB-01 - metal box version (Integral potentiometer input, 2A output, no ramps, fixed dither)	Panel mount version P/N: 4000225 shown (also available in a remote metal box with power on/off switch). Click image for Product Overview.
ANALOG VALVE DRIVERS - PWM Controlled Solenoid Driver This PWM controller supplies a proportional solenoid with current proportional to a digital pulse width modulated (PWM) signal input. The user can adjust the maximum current output, dither frequency, dither level as well as the independent rising and falling ramps to suit their application. The unit is available in a DIN rail mount housing, an IP67 rated rugged metal box or as a stand alone PCB board. Click on a part number for Technical Data. Part Numbers: PWMC-PCB-2A - PWM input, 2A or 1.2A output (PCB board) PWMC-SMB-2A-IP7-1.5M - PWM input, 2A or 1.2A output (metal box) PWMC-DR-2A - PWM input, 2A or 1.2A output (DIN rail)	Click image for Product Overview.
ANALOG VALVE DRIVERS - Hot Shot Coil Saver Costs are reduced if the minimum sized valve is selected for an application, and if the solenoid coil life can be extended. The Hot Shot Coil Saver provides full battery power to improve initial motion in the solenoid, and then drops down to a holding level to save excess current from acting on the coil . Part Number: CS-xx-yyy - 3 sec. response xx = holding power as a % of input power yyy = initial output time interval (mSec)	Click image for Product Overview.

OEM Product Development

Many mobile applications require special consideration and hence standard products are not always available to do the job right. We have developed a strong technology base from which innovative, robust, and cost effective solutions can be produced on an aggressive schedule.
